Feature Engineering and Preprocessing

Overview

With the target and outcome cohorts populated in the database, the next step is to give each patient a numerical fingerprint - a row of features that summarises their clinical history in the 365 days before their index date.

This single constraint governs every query on this page: everything used to predict must come from before the index date. Any future information would constitute data leakage and make the model useless in practice.

Feature Sources

Features are drawn from six OMOP CDM tables, each capturing a different dimension of a patient's clinical picture.

OMOP Table	Features Extracted
person	Age at index date, sex, race, ethnicity
condition_occurrence	Count of distinct diagnoses
drug_exposure	Distinct drugs, total days of supply, total quantity, most common route
procedure_occurrence	Count of distinct procedures
measurement	Maximum recorded measurement value, most common unit
observation	Count of distinct observations, maximum observation value

All queries share the same lookback pattern:

AND table.start_date BETWEEN cohort.cohort_start_date - INTERVAL 365 DAY
                         AND cohort.cohort_start_date

Extracting Features

The code below connects to the DuckDB database and extracts one feature table per OMOP domain. All queries filter to cohort_definition_id = 1 (the target cohort) and apply the 365-day lookback window.

using DuckDB, DBInterface, DataFrames

# conn, SCHEMA, TARGET_COHORT_ID are established by run.jl and shared with all sub-scripts
const conn   = DBInterface.connect(DuckDB.DB, config["database"]["path"])
const SCHEMA = config["schema"]["name"]
const COHORT = "cohort"
const TARGET = config["cohorts"]["target_cohort_id"]  # 1 = hypertension
const WINDOW = 365    # lookback days

Demographics

Demographic features come from the person table without a lookback filter - a patient's age, sex, race, and ethnicity at their index date are static characteristics.

demographics_df = DataFrame(DBInterface.execute(conn, """
    SELECT
        c.subject_id,
        YEAR(c.cohort_start_date) - p.year_of_birth AS age,
        p.gender_concept_id,
        p.race_concept_id,
        p.ethnicity_concept_id
    FROM $SCHEMA.$COHORT c
    JOIN $SCHEMA.person p ON c.subject_id = p.person_id
    WHERE c.cohort_definition_id = $TARGET
"""))

Conditions

The concept_ancestor join expands each specific diagnosis to its SNOMED ancestors, so the count captures both the precise diagnosis and its broader categories.

conditions_df = DataFrame(DBInterface.execute(conn, """
    SELECT
        c.subject_id,
        COUNT(DISTINCT ca.ancestor_concept_id) AS condition_count
    FROM $SCHEMA.$COHORT c
    JOIN $SCHEMA.condition_occurrence co ON c.subject_id = co.person_id
    JOIN $SCHEMA.concept_ancestor ca     ON co.condition_concept_id = ca.descendant_concept_id
    WHERE c.cohort_definition_id = $TARGET
      AND co.condition_start_date
          BETWEEN c.cohort_start_date - INTERVAL $WINDOW DAY
              AND c.cohort_start_date
    GROUP BY c.subject_id
"""))

Drug Exposure

The concept_ancestor join rolls up specific drug ingredients to their RxNorm drug class ancestors, capturing both fine-grained and generalised medication exposure.

drugs_df = DataFrame(DBInterface.execute(conn, """
    SELECT
        c.subject_id,
        COUNT(DISTINCT ca.ancestor_concept_id) AS drug_count,
        SUM(de.days_supply)                    AS total_days_supply,
        SUM(de.quantity)                       AS total_quantity,
        MAX(de.route_concept_id)               AS max_common_route
    FROM $SCHEMA.$COHORT c
    JOIN $SCHEMA.drug_exposure de   ON c.subject_id = de.person_id
    JOIN $SCHEMA.concept_ancestor ca ON de.drug_concept_id = ca.descendant_concept_id
    WHERE c.cohort_definition_id = $TARGET
      AND de.drug_exposure_start_date
          BETWEEN c.cohort_start_date - INTERVAL $WINDOW DAY
              AND c.cohort_start_date
    GROUP BY c.subject_id
"""))

Measurements

Measurements capture lab values and vitals. For each patient we take the maximum recorded value and most common unit within the lookback window.

measurements_df = DataFrame(DBInterface.execute(conn, """
    SELECT
        c.subject_id,
        MAX(m.value_as_number) AS max_measurement_value,
        MAX(m.unit_concept_id) AS max_common_unit
    FROM $SCHEMA.$COHORT c
    JOIN $SCHEMA.measurement m       ON c.subject_id = m.person_id
    JOIN $SCHEMA.concept_ancestor ca ON m.measurement_concept_id = ca.descendant_concept_id
    WHERE c.cohort_definition_id = $TARGET
      AND m.measurement_date
          BETWEEN c.cohort_start_date - INTERVAL $WINDOW DAY
              AND c.cohort_start_date
    GROUP BY c.subject_id
"""))

Procedures

procedures_df = DataFrame(DBInterface.execute(conn, """
    SELECT
        c.subject_id,
        COUNT(DISTINCT ca.ancestor_concept_id) AS procedure_count
    FROM $SCHEMA.$COHORT c
    JOIN $SCHEMA.procedure_occurrence po ON c.subject_id = po.person_id
    JOIN $SCHEMA.concept_ancestor ca     ON po.procedure_concept_id = ca.descendant_concept_id
    WHERE c.cohort_definition_id = $TARGET
      AND po.procedure_date
          BETWEEN c.cohort_start_date - INTERVAL $WINDOW DAY
              AND c.cohort_start_date
    GROUP BY c.subject_id
"""))

Observations

observations_df = DataFrame(DBInterface.execute(conn, """
    SELECT
        c.subject_id,
        COUNT(DISTINCT ob.observation_concept_id) AS observation_count,
        MAX(ob.value_as_number)                   AS max_observation_value
    FROM $SCHEMA.$COHORT c
    JOIN $SCHEMA.observation ob ON c.subject_id = ob.person_id
    WHERE c.cohort_definition_id = $TARGET
      AND ob.observation_date
          BETWEEN c.cohort_start_date - INTERVAL $WINDOW DAY
              AND c.cohort_start_date
    GROUP BY c.subject_id
"""))

Distribution Check

Before attaching labels and preprocessing, it is worth inspecting the feature distributions to catch obvious data quality problems - all-zero columns, implausibly extreme values or skewed distributions.

Attaching Outcome Labels

Each patient receives a binary label: 1 if they appear in the outcome cohort (pneumonia within 365 days of their index date), 0 otherwise. The join is deliberately simple - presence in cohort_definition_id = 2 is the only criterion.

outcome_df = DataFrame(DBInterface.execute(conn, """
    SELECT subject_id, 1 AS outcome
    FROM $SCHEMA.$COHORT
    WHERE cohort_definition_id = 2
"""))

# Left join - patients not in the outcome cohort receive `missing`, replaced with 0
df = leftjoin(features_df, outcome_df; on = :subject_id)
df[!, :outcome] .= coalesce.(df[!, :outcome], 0)

DBInterface.close!(conn)

The resulting dataset has one row per patient:

Column	Type	Meaning
subject_id	Int	Patient identifier
age	Float	Age at cohort entry
gender_concept_id	Int	Sex (OMOP concept ID)
race_concept_id	Int	Race (OMOP concept ID)
ethnicity_concept_id	Int	Ethnicity (OMOP concept ID)
condition_count	Int	Distinct diagnoses in lookback window
drug_count	Int	Distinct drug classes in lookback window
total_days_supply	Int	Total medication days supplied
max_measurement_value	Float	Highest lab/vital value recorded
procedure_count	Int	Distinct procedures in lookback window
observation_count	Int	Distinct clinical observations
outcome	0 / 1	Did this patient develop pneumonia?

Save the Matrix

Save to CSV so preprocessing and modeling can be run independently without re-querying the database:

using CSV
CSV.write(joinpath(OUTPUT_DIR, "plp_features.csv"), df)
println("Saved $(nrow(df)) rows to plp_features.csv")

OUTPUT_DIR is defined in run.jl as src/workflows/patient_level_prediction/output/ and is created automatically on first run.

Preprocessing

The feature matrix needs three preparation steps before it is ready for modeling.

1. Drop Low-Signal Columns

The distribution check may reveal columns that add noise rather than signal. In practice, total_quantity and max_observation_value are often very sparse or unreliable in synthetic data and are dropped here:

using InvertedIndices: Not
select!(df, Not([:total_quantity, :max_observation_value]))

2. Impute Missing Values

Patients with no records in a given OMOP domain have missing for that domain's features. Replace numeric gaps with 0 ("no events recorded") and categorical gaps with "unknown":

for col in names(df)
    if eltype(df[!, col]) <: Union{Missing, Number}
        df[!, col] = coalesce.(df[!, col], 0)
    else
        df[!, col] = coalesce.(df[!, col], "unknown")
    end
end

3. Standardize Numeric Features

Logistic regression is sensitive to feature scale; large-magnitude features dominate the gradient. Standardize each numeric column to zero mean and unit variance:

using Statistics

num_features = [
    :age, :condition_count, :drug_count, :total_days_supply,
    :max_measurement_value, :max_common_route, :procedure_count, :observation_count,
]

for col in num_features
        col_std = std(skipmissing(df[!, col]))
        if col_std != 0
            df[!, col] .= (df[!, col] .- mean(skipmissing(df[!, col]))) ./ col_std
        end
    end

4. Encode Categorical Variables

OMOP stores sex, race, and ethnicity as integer concept IDs. Converting them to CategoricalArray tells MLJ.jl to treat them as unordered categories rather than ordinal numbers:

using CategoricalArrays

df.gender_concept_id    = categorical(coalesce.(df.gender_concept_id,    "unknown"))
df.race_concept_id      = categorical(coalesce.(df.race_concept_id,      "unknown"))
df.ethnicity_concept_id = categorical(coalesce.(df.ethnicity_concept_id, "unknown"))
